ASC ASC folding scaffold 135x190 working height 4.7 m + 2 outriggers
ASC folding scaffold 135x190 working height 4.7 m + 2 outriggers
€1.622,00 Excl. VAT
€1.962,62 Incl. VAT
ASC ASC folding scaffold 135x190 working height 4.7 m + 2 outriggers
ASC folding scaffold 135x190 working height 4.7 m + 2 outriggers
€1.622,00

Cheaper somewhere else?

Let us know!

+32 (0) 496 532 330 [email protected]

ASC folding scaffold 135x190 working height 4.7 m + 2 outriggers

Brand: ASC
|
Click to enlarge image
€1.622,00 Excl. VAT
€1.962,62 Incl. VAT
ASC foldable scaffold 135x190 cm working height 4.70 m. Professional folding scaffold, maximum load capacity 450 Kg. Expandable to a working height of 7.85 m.
Add to comparison list
View comparison list
In stock
You have got counting... hours
  • Largest range in Belgium
  • Quick service. Delivery from stock.
  • Professional advice +32 (0) 496 532 330
Information

The A-Line folding scaffold 135 cm wide is standard equipped with ribbed extension tubes for height expansion. This foldable mobile scaffold is expandable to a working height of 7.85 m. The indoor scaffold can be easily increased with extra frames & braces, these are always available from stock!

The ASC aluminum folding scaffolding 135x190 is easy to use and easy to store/transport. The horizontal rungs of the construction frames have an anti-slip profile. The platform is 60 cm wide, braces can be placed along the platform. The platform can be moved every 28 cm.

Scaffold parts:

  • 2x ASC folding scaffold 135x190 frame D135-6
  • 1x ASC platform 190, wood
  • 1x ASC platform with hatch 190, wood
  • 2x ASC horizontal brace 190
  • 1x ASC diagonal brace 190
  • 2x Stabilizer 200
  • 4x Scaffold wheel 150 mm rubber
  • 10x Locking clip

What does working height mean?

Working height is understood to mean the height at which you can work when standing on the platform. The formula used for this is platform height + 2 meters = working height. This is an indication and may differ slightly in practice, depending on your own body measurements.

Specifications
Sizes scaffold Length x Width x Heigth (m): 1.90 x 1.35 x 3.70 m
Maximum working height (m): 4.70 m
Maximum platform height (m): 2.70 m
Weight (kg): 83 kg
Maximum load platform (kg): 250 kg
Maximum load scaffold (kg): 450 kg
Wheels: 150 mm / rubber / not adjustable
Type user: Professional
Scaffolding class: Classe III (200 kg/m²)
Norm: NEN-EN 1004 / EN 1298 / TÜV-GS
Guarantee: 10 years
